XRF is a widely used, proven, and accepted method of chemistry analysis and determination of purity and
fineness of precious metals. XRF analysis is a multi-elemental testing alternative that is quicker and less
expensive than fire assay and chemical tests. XRF provides on-the spot analysis of your silver, platinum,
and gold metals and impurities, making it an easy way to boost customer confidence and ensure dealer
reliability.
Given the current high value of gold, quantifying its fineness and purity is more critical than ever.
Whether you buy gold, sell or produce jewelry, fabricate metal, or recycle scrap metal, you need a fast,
highly accurate method to determine karat (gold content) for quality control and pricing.
EDX6000E Gold Analyzer is an easy to use, high precision XRF gold testing machine cost-effective method to obtain alloy chemistry and karat classification with one non-destructive test.
Main Feature
Integrated measurement system(No need extra PC)
High precision(precise to 0.05%)
Non-destructive
Fast results(30s-200s)
Technical specificationsMeasurable elements: Ni, Zn, Au, Ag, Cu,Pt, Pd, Ir etc
Measurement Precision (Standard Deviation Statistic)
0.05%~0.1% ( main element content over than 96%)
0.01um~0.05um (for coating element analysis)Detector: Aptek Si-Pin Detector
Detector resolution:165ev
Tube voltage: 5-50KV
Tube current: 50-1000μATest time: 60~100s
Ambient humidity: <=70%Ambient temperature: 5℃-30℃
Power: AC220V+-5V( AC purified stabilized voltage power supply is recommended)
